4.2 Connecting the indicator 4 Installation/Maintenance
S122 User / Service Instructions 30
4.2 Connecting the indicator
1. Slide the indicator onto the bracket until it clicks into
place.
2. Plug the connector from the platform into the indicator.
3. To adjust the angle of the indicator, loosen the knob A
and move the indicator until it clicks into the required
position.
4. To remove the indicator, disconnect, then press the
release catch B and carefully slide the indicator off the
platform.
A
B
