Section 319–29E–202
14
(c) ESF DATA LINK: The bit-oriented command and response message 0 001001 0 11111111 for 16 milli-
seconds to loop up. The bit-oriented command and response message 0 010010 0 11111111 for 16
milliseconds to loop down.
(d) LOOPBACK TIMEOUT: 20 Minutes
10.1.2. Power
(a) INPUT: Voltage Requirements, –42.5 to 56Vdc; Current Requirements, see Table 1.
10.2
Physical Specifications
The physical specifications of the 3192-9E are as follows:
Table 4.
Physical Specifications
Feature
U.S.
Metric
Height
4.75 inches
12.06 cm
Width
0.687 inches
1.746 cm
Depth
10.5 inches
26.67 cm
Weight
12 oz.
198 g
Temperature
–40
_
to 149
_
F
–40
_
to 65
_
C
Humidity
To 95% (no condensation)
