Measure and mark the horizontal of 75 mm from the center line distance between the holes
on the flat surface as describe in the illustration below. Use 2 pieces of M4.0 screws for 6
mm holes and secure the F17HD+ on the flat surface.

75mm

75mm

M4

A

A

n

n

t

t

i

i

-

-

g

g

l

l

a

a

r

r

e

e

S

S

h

h

e

e

e

e

t

t

The anti-glare sheet is a special coated film that helps eliminate any glare that maybe
encountered while displaying very shiny objects or glossy surfaces such as magazines and
pictures. To use, simply place the anti-glare sheet on top of the shiny document to reduce
reflected light.
