ABF3260 - ABF3648 - ABF3660 - ABF3672 - ABF4260 - ABF4860
1
1A.
silicone sealant along the channel.
INSTALL TILING FLANGE.
2 PREPARE DRAINING PIPE.
2A.
-
modate plumbing. The 2” (5.0cm) drain pipe should
Note: Dimensions D and E from wall to center of
drain. ( See chart on page 3)
Dim E
2B.
Position base. Verify that the draining pipe location
matches the actual location of the base drain.
Remove the base.
Dim D
* DOUBLE THRESHOLD INSTALLATION TYPE SHOWN
1B.
using self drilling screws #6 x 1”
1A 1B
