INSTRUCTION MANUAL
INSTALL THE HINGES.
5
FASTEN THE SUPPORT BAR.
6
5A.
Do not tighten all the way for this step to allow other
door adjustments.
6A.
Loosen the glass clip. Align the slotte to the
inside of the shower.
tub. Level it and trace an arc on the wall.
6C.
Isolate the wall bracket and drill a hole, using a 1/4˝
drill bit through the wall. Locate the position of this
hole by way of the wall bracket. Insert a wall plug.
3
5
INTERIOR
SHOWER SIDE
6A
6B
6C
