3c install the fixed panel, Insert the fixed panel gasket – Alumax L-STSX24 User Manual
Page 8
8
INSTRUCTION MANUAL
3
4
3b
3B
3a
INTERIOR
SHOWER SIDE
12
11a
11b
3C
INSTALL THE FIXED PANEL.
3
INSERT THE FIXED PANEL GASKET.
4
3A.
the aluminum “u” channel. Secure it with the plier.
3B.
Combine the 3 3/8˝ screws (#12) with the inner
3C. Snap the screw caps (#11a) over the screws.
4A.
threshold (#4). Insert it with a 2˝ x 6˝ x 1/2˝ block and a
mallet. Trim the excess using the cutting plier.
2
3
9
3
3A
INTERIOR
SHOWER SIDE
15
