INSTRUCTION MANUAL

Secure the glass fastener and wall bracket screws to

complete the installation.

5

INSTALL THE PIVOT SUPPORT BAR.

INSTALL DOOR PANEL

6

6A.

Do not tighten all the way for this step to allow other

door adjustments.

3a

5

INTERIOR

SHOWER SIDE

1

5A.

panel. The slotted screw head should be on the

inside of the shower.

5B.

shower as shown. Level it and trace the outline of

the wall bracket on the wall.

5C.

Isolate the wall bracket and drill a hole, using a 1/4”

drill bit (ceramic drill bit if necessary) through the wall.

Locate the position of this hole by way of the wall

bracket. Insert a wall plug.

Secure the wall bracket to the wall by way of the

screw. Assemble the cylindrical joint to the wall

bracket.

5E.

5D.

6D

6E

5D

5E

5B

5C

5A
