FASTEN THE HINGES TO THE WALL.
2
2A. Fasten the hinges (#8) to the wall as illustrated.
PREASSEMBLE THE DOOR.
3
3B.
Install the 2 spacing blocks (#7) onto the
bottom lip of the gasket.
3A.
Temporarily insert the bottom door gasket
(#11) under the door panel.
9
3A
3B
INTERIOR
SHOWER SIDE
3C
6
3C.
Place the magnetic gasket (#6) on top of
the bottom door gasket (#11) and insert it
on the door panel using a mallet.
6
7
FINAL RESULT
LIP
INTERIOR
SHOWER SIDE
9
6
8
11
20
11
20
INTERIOR
SHOWER SIDE
