11
INSTRUCTION MANUAL
2
9
2
8B
FASTEN THE “U” CHANNEL.
8
8B. Realign the aluminum “U” channel on the threshold
and drill a hole using a 1/8˝ drill bit at about 2˝ from the
edge. Put a drop of silicone in the hole and fasten the
“U” channel with a 3/4˝ long screw (#19). Place the clear
setting block (#14) back over the screw.
OPTIONAL
RUN A BEAD OF SILICONE IN THE
ALUMINUM “U” CHANNEL.
8A. Mark the location of the aluminum “U” channel (#5) on
5
9A.
the aluminum “u” channel. Secure it with the locking
plier.
9B. Combine the 3 3/8˝ screws (#17) with the inner
9C. Snap the screw caps (#16a) on the screws.
INSTALL THE FIXED PANEL.
9
19
14
19
8A
6
3b
17
16a
16b
9A
9B
9C
5
6
5
INTERIOR
SHOWER SIDE
