6c 9a – Alumax P-DR2W-48-60-CW User Manual
Page 13
13
7
THRESHOLD
6
CONTINUED
3
Remove the fixed panel (18) so as to
allow placement of the threshold (9)
onto the base. Ensure that a bead of
silicone (S) is applied to the underside of
the threshold before installing.
Secure glass clip (6) and bottom
center guide (7) with self drilling screws
(20) and insert gaskets.
5
Mark the screw locations for the wall
bracket for running rail (3) on the wall as
well as the placement the glass clip (6) and
bottom center guide (7).
6C
9A
S
7
7
6
6
20
7
6
9
18
3
6C
