10
Cut the drip rail [V] to the length of the bottom
rail minus 11/16". Clean the bottom door rail and the
drip rail thoroughly to ensure proper adhesion. Unroll
the double stick tape [Y] and carefully apply it to the
back of the drip rail (do not peel the tape backing yet).
Insert the tapered drip vinyl [W] into the drip rail.
Position the drip rail flush with the bottom and pivot
side of the door panel [L], then raise the strike side
until the bottom edge of the drip vinyl is parallel to the
curb [A]. Mark the location of each end of the drip rail.
Adjust the drip vinyl [W] by sliding it left or
right until it just touches the curb. Trim the vinyl
(flush with the pivot end and notch 1/4" longer
than the drip rail as shown on the strike end).
Secure it with one #6 x 3/8" truss head screw [E]
in the pivot end of the drip rail.
The drip plug [X] is supplied with a left and right
hand plug together. Break the right and left drip
plug apart and insert the appropriate plug into
the high (strike) side of the drip rail. Discard the
unused drip plug. Peel off the tape backing and
carefully press the drip rail to the door in the marked
position.
11
Neatly caulk the inside perimeter of the
shower curb and wall jambs.
NOTE: The caulking should be allowed to cure for
twenty-four hours before using your new shower
enclosure.
