Page 5
Obsidian Series 800D
USER MANUAL
5
1.2.
Parts List
1
– Side Panels
9
– HDD Drive Dock Door
17
– Lower HDD bay shield
2
– 140mm rear fan
10
– Front Bezel
18
– HDD Drive Dock Fan Shroud
3
– 3 x 120mm top fan vents
11
– Lower HDD bay cover
19
– 140mm HDD fan
4
– CPU backplate cover
12
– Lower HDD bay rails
20
– HDD SATA Backplane Shield
5
– Small rubber grommet
13
– 140mm intake fan
21
– Front I/O ports
6
– Large rubber grommet
14
– Case feet
22
– Front I/O port cover
7
– PSU bay shield
15
– HDD Drive Dock trays
8
– 5.25” Bay Covers
16
– Tool-free mechanism
