Installing Batteries

install four size-AA batteries.

Open the cover.

• Slide Mie battery compartrneni cover as

shown by the arrow and open it.

Install the batteries.

• Make sure the + and - battery contacts are

correctly oriented as shown in the battery
compartment.

Close the cover.

• Close the battery compartment cover and

slide it as shown by the arrow.

Recycling Time and Flash Count (with size-AA alkaline batteries)

Flash Cbimt OAppiiiMoj"

QufcKFlash

- Rotnial Flash

0.1 -3

0.1 -e

100-700

■ Based on new size-AA alkarine batteries and Canon’s testing siandaids,
• Quick flash enabies a flash to be fired before flash-ready (p.10).

Since the shape of their contacts Is not standardized, using non-alkaline size-AA
batteries may result in faulty battery connection.

Q • Use (our new batteries of (he same-brand and type. Do not mix battery types. When

replacing batteries, replace all four batteries at the same time.

« Siifi'AA Ni'MH or lithium batteries can also be used.
