3-7
Cisco Unified IP Phone Services Application Development Notes
OL-20949-01
Chapter 3 CiscoIPPhone XML Objects
XML Object Definitions
Note
For the directory listing, the Cisco Unified IP Phone displays the appropriate softkeys that are needed to
dial the numbers that are listed on the display. The softkeys include the Edit Dial softkey, which allows
users to insert access codes or other necessary items before dialing.
The
Title
and
Prompt
tags in the XML object have the usual semantics. A single
CiscoIPPhoneDirectory
object can contain a maximum of 32
DirectoryEntry
objects. If more than 32
entries must be returned, use multiple
CiscoIPPhoneDirectory
objects in subsequent HTTP requests.
Note
The 6900 series IP phones does not display the Title and Prompt menu fields at the same time. If both
Title and Prompt fields are defined at the same time, then these phones display only the Prompt field.
Custom Directories
You can use the Cisco Unified Communications Manager enterprise parameter, “URL Directories” and
CiscoIPPhone XML objects to display custom directories. The “URL Directories” points to a URL that
returns a
CiscoIPPhoneMenu
object that extends the directories menu. The request for “URL Directories”
must return a valid
CiscoIPPhoneMenu
object, even if has no
DirectoryEntry
objects.
To create a custom directory, use the following optional objects in the order in which they are listed:
1.
Use the
CiscoIPPhoneInput
XML object to collect search criteria.
2.
Use the
CiscoIPPhoneText
XML object to display status messages or errors.
3.
Use the
CiscoIPPhoneDirectory
XML object to return a list of directory entries that can be dialed.
You can omit the
CiscoIPPhoneInput
or
CiscoIPPhoneText
objects. You can display multiple
CiscoIPPhoneDirectory
objects by specifying an HTTP refresh header that points to the URL of the next
individual directory object, which the user accesses by pressing the Next softkey on the phone.
CiscoIPPhoneImage
The CiscoIPPhoneImage provides a bitmap display with a 133 x 65 pixel pane that is available to access
services. Each pixel includes four grayscale settings. A value of three (3) displays as black, and a value
of zero (0) displays as white.
Note
The phone uses an LCD display, which inverts the palette.
The
CiscoIPPhoneImage
XML type lets you use the Cisco Unified IP Phone display to present graphics
to the user.
Definition
