DEPTH-OF-FIELD INDICATORS
Depth of field (i.e., the zone of acceptable image focus) can be checked by reading the
color-coded
depth-of-field
indicators
®
engraved
on
the
lens
barrel.
The
pairs
of
color
ed lines on either side of the white distance scale index line correspond to f/numbers of
the
same
color
on
the
aperture
scale
®.
You
can
also
observe
the
depth
of
field
through the viewfinder by simply pressing the depth-of-field preview button on the cam
era body,
INFRARED PHOTOGRAPHY
In
infrared
photography,
the
plane
of
sharpest
focus
is
slightly
more
distant
than
the
one
produced
by
visible
light
and
seen
through
the
viewfinder.
To
compensate
for
the
shift in focus, the lens has a curved red line on the lens barrel. After focusing the image
sharply
through
the
viewfinder,
check
the
focused
distance.
Then
turn
the
focusing/
zooming ring to the left until the red line lines up with the prefocused distance,
SPECIFICATIONS
Focal length: 100mm to 300mm
Maximum aperture: f/5,6
Lens construction: 14 elements in 10 groups
Picture angle: 24°20' to 8° 10'
Distance scale: Graduated in meters and feet from 2m (7ft) to infinity (■»): macro fo
cusing
mode
at
only
100mm
focal
length
setting;
at
this
setting,
down
to
0.71m
(2.3ft)
Focus/zoom
control:
Via
a
single
control
ring;
focusing
is
done
by
rotating
the
ring,
zooming by sliding it in or out; reference scale for focal length settings of 100mm,
135mm,
200mm
and
300mm
are
provided
on
the
lens
barrel;
in
macro
mode,
zooming is impossible from 2m (7ft) to 0.71m (2.3ft)
Macro focusing function: Operable only with the focusing/zooming ring set to 100mm
focal length setting; at this setting, close focusing down to 0.71m (2.3ft) is possible
Aperture scale: f/5.6 to f/32 on both standard and aperture-direct-readout scales
Diaphragm: Fully automatic
Exposure measurement: Via fuU-aperture method
Mount: Nikon F m ount
Attachment size: 62mm dia. (P=0.75)
Dimensions: 74mm dia. x 207mm long (overall); 199mm extension from flange
Weight: Approx. 930g
ACCESSORIES
Supplied
Optional
62mm snap-on front lens cap
Rear lens cap LF-1
62mm screw-in lens hood HN-24
62mm screw-in filters
Hard lens case CL-40
Teleconverter TC-201*
Teleconverter TC-200*
Teleconverter TC-14B
Teleconverter TC-14
* Vignetting or other performance deterioration may be noticeable in the image re
corded on the film.
10
