Seville 1635
(continued)
Item/Model Number
Part Number
0-05 Notes:
1. In this diagram and throughout this manual, 'left' and
'right' mean as you face the stove.
2. Use only Vermont Castings Glass Panel part
number 30000774 for replacement.
3. Part numbers for cast iron parts in this diagram are
for 'classic' (plain black) stoves. When ordering
enamelled parts, be sure to specify color.
4. Hardware in this stove is instandard U.S. (inch)
sizes. Most hardware items are available at local
hardware stores.
To learn the name of the dealer nearest you, call or
write:
Vermont Castings, Majestic Products
410 Admiral Blvd.
Mississauga, Ontario L5T 2N6
905 670-7777
Maintenance Kits available from your dealer:
#1884 Gasket Kit
#1877 Thermostat Kit
11. Bottom
30001434
12. Bottom, Inner
30000759
13. Ashlip
30000758
14. Ashpan
30000777
15. Firebrick Support
30000751
16. Back
30001443
17. Fireback Brick Ledge
30000753
18. Leg (4)
30000756
19. Leg Bolt, 1/4-20x1" hex bolt (4)
1201376
20. Heavy Leg Washer
30001633
21. Primary Air Manifold
30001433
22. Grate, Wood
30001432
23. Door Baffle
30000835
24. Front
30000752
25. Door
30000757
26. Door Hinge Pin, 1” (2)
1600416
27. Door Gasket, 3/8” - Low D
1203589
28. Primary Air Flap
30001435
29. Door Handle Catch
30000365
30. Wooden Handle
30000366
31. Door Handle Shaft
30000364
32. Roll Pin, 3/16” x 1”
1201833
33. Glass Gasket, horizontal
30000896
34. Glass Gasket, vertical (2)
30000895
35. Glass Panel
2
30000774
36. Glass Clip (2)
30000840
37. AIr Deflector
30000985
38. Door Air Wash Manifold
30000747
39. Firebrick, (14)
1601103
40. Friction Spring
1201846
41. Thermostat Sub-Assembly
30001442
42. Ball Chain, Thermostat
1201960
43. Rear Convection Shroud Assembly
30001436
44. Bottom Heat Shield
30000897
Thermostat Cover
30001437
Hardware
#10 Flat Washer
1202423
1/4-20x3/4" Hex Screw (2)
1201374
1/4-20x1
¹⁄₄
" Flt Hd Phillips Screw (2)
1200811
1/4-20x1
³⁄₄
" Flat Hd Phillip Screw (6)
1200830
1/4-20 x 1-1/2” Stud, Full Thrd Crs (4)
1204214
1/4-20 Hex Nut, (13)
1203210
1/4 Flat Washer (8)
1202473
10-24x3/8" Round Hd Slotted Screw (4)
1200983
1/4-20x1
¹⁄₂
" Hex Head Screw (8)
1201326
#10 x 1/2” SMS Pan Head Screw (6)
1202058
1/4-20x3/8" Pan Hd Phillips Screw
1200993
10-24 x 5/8” Pan Hd Phillips Screw
1200986
