11
Vermont Castings Seville
30001490
Fig. 15 Parallel installation, vertical chimney connector, two
wall shields.
1
( 2 5 m m )
1
(25mm)
40
(1016mm)
40
(1016mm)
36
(914mm)
36
(914mm)
ST483
1
( 2 5 m m )
1
(25mm)
40
(1016mm)
40
(1016mm)
36
(914mm)
Fig. 16 Parallel installation with rear wall pass-through, two
wall shields.
ST484
1
2 5 m m
1
25mm
40
(1016mm)
40
(1016mm)
36
(914mm)
36
(914mm)
Fig. 17 Corner installation, vertical chimney connector, two
wall shields.
ST485
