Alcove Installations
The Seville is approved for installation into an alcove
constructed to maintain the clearances diagramed in
Figure 18.
Fig. 18 Alcove specifications.
Unprotected
Surfaces
Protected
Surfaces
(per NFPA 211)
A
Min. Width
B
Max. Depth
C
Stovetop to Ceiling
52”
(1321mm)
27”
(686mm)
36”
(914mm)
D
Connector to Ceiling
E
Connector to Wall
12”
(305mm)
10”
(254mm)
34”
(864mm)
56”
(1422mm)
24”
(610mm)
17”
(432mm)
18”
(457mm)
C
D
B
A
E
ST487
With
Single-wall
Connector
With
Single-wall
Connector
and
Connector
Heat
Shields,
or
Double-wall
Connector
Stove Installed
Parallel to Wall
Stove in Corner
UNPROTECTED SURFACES
PROTECTED SURFACES
Stove Installed
Parallel to Wall
Stove in Corner
D
E
F
F
A
B
J
K
L
I
G
C
C
I
H
L
ST486
