CRAFTSMAN 2200 PSI HIGH PRESSURE WASHER 580.762200
Craftsman 4“Cycle Engine 143.986714
,
Item Part# Description
Qty.
Item Part#
Description
Qty.
0
640147
1
631615
631767
631184
631183
640070
650506
16
631807
17
651025
18
630766
20
640016
20A 640053
Carburetor
Oncl. 184 of Engine
Parts List)
Throttle Shaft & Lever
Assembly
Throttle Return Spring
Dust Seal Washer
Dust Seal (Throttle)
Throttle Shutter
Shutter Screw
Fuel Fitting
Throttle Crack
Screw/ldle Speed
Screw
Tension Spring
Idle Restrictor Screw
Idle Restrictor
Screw Cap
25 631867
27
631024
28
632019
29
631028
30
631021
31
631022
35
36045A
36
632745
37
632547
40
640083
44 27110
47
630748
48
631027
Float Bowl
1
Float Shaft
1
Float
1
Float Bowl “0” Ring
1
Inlet Needle, Seat,
k Clip (Incl. 31)
1
Spring Clip
1
Primer Bulb/Retainer
Ring
1
Main Nozzle Tube
1
Main Nozzle Tube
“0” Ring
2
High Speed Bowl Nut
1
Bowl Nut Washer
1
Welch Plug, Idle
Mixture Well
1
Welch Plug,
Atmospheric Vent
1
