UNASSEMBLED PARTS
Bagger
1 / 4 x 2 0 x 1.25”
Carriage Bolts
1 / 4 x 2 0 x 1 . 1 5
Shoulder Bolts
1 / 4 x 2 0
Flange Lock Nuts
Retainer Spring clip
Clevis Pin
Steering Wheel
T
J
Steering Wheel
Adapter
(
A
i'-—"
\
\
A
y )
y
/
Steering Boot
rm
(1) Bolt
Steering
Extension
Shaft
(1) Large
Flat Washer
(1) Lock
Washer
Seat
(1) Bolt
(1) Seat
Slope Sheet
Key(s)
