OPERATION
These symbols may appear on your tractor or in literature supplied with the product. Learn
and understand their meaning.
N H L l\l 4»
REVERSE NEUTRAL HIGH LOW CHOKE FAST SLOW
m
© 0
/iff ^)IU
n i i i i
ENGINE OFF REVERSE
OPERATION
SYSTEM (ROS)
ENGINE ON ENGINE START PARKING BRAKE MOWER HEIGHT MOWER LIFT
ID a
LIGHTS ON FUEL BATTERY REVERSE FORWARD CRUISE CONTROL
ATTACHMENT ATTACHMENT
CLUTCH DISENGAGED CLUTCH ENGAGED
!
-0-
FREE WHEEL
(Automatic Models only)
A
Failure to follow instructions
could result in serious injury or
death. The safety alert symbol
is used to identify safety inform­
ation about hazards which can
result in death, serious injury
and/or property damage.
CLUTCH/BRAKE
PEDAL
DANGER, KEEP HANDS
AND FEET AWAY
OPERATE ONLY
WITH BAGGER
DO NOT OPERATE
WITHOUT BAGGER
KEEP AREA CLEAR SLOPE HAZARDS
(SEE SAFETY RULES SECTION)
DANGER indicates a hazard which, if not avoided,
will result in death or serious injury.
WARNING indicates a hazard which, if not avoided,
could result in death or serious injury.
CAUTION indicates a hazard which, if not avoided,
might result in minor or moderate injury.
CAUTION when used without the alert symbol,
indicates a situation that could result in damage
to the tractor and/or engine.
HOT SURFACES indicates a hazard which,
.biiMiito avoided, could result in death, serious injury
A
Ü
and/or property damage.
/ FIRE indicates a hazard which, if not avoided,
- could result in death, serious injury and/or
property damage.
