REPAIR PARTS
TILLER • < MODEL NUMBER 917.293320
HANDLES
KEY
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
PART
NO.
164743
141406
110673X
127254X
6712J
137119
110641X
71191008
72010520
110646X
STD624003
81328
138295
109313X
110702X
STD533710
109229X
DESCRIPTION
Throttle, Control
Grip, Handle
Grommet, Handle
Bar, Drive Control Assembly
Cap. Vinyl
Panel, Control
Bushing. Spilt
•Screw, Pan Head #10-24
•Bolt, 5/16-18
X 2-1/2
Handle, Grip
'■Clip, Hairpin
Bolt, Shoulder
Handle, Shift
Grommet. Rubber
Rod, Shift
‘Bolt, Carriage 3/8-16 x 1 Gr. 5
Lock, Handle
KEY PART
NO. NO.
18 STD541437
19 19131611
20 109228X
21 150628
22 165197
23 86777
24 9484R
25 73970500
26 110675X
27 STD541025
28 STD5S1125
29 STD541462
30 150696
DESCRIPTION
•Nut, Centerlock 3/8-16
Washer 13/32 x 1 x 11 Ga.
Lever, Lock, Handle
Handle, /^emUy
Clip, Plastic, Cable
Screw. Hex. Washer Hd, Slotted
#10-24 X1/2
Clip
Locknut, Hex, Range
Clutch, Cable
•Nut, Hex 1/4-20
•Washer, Lock 1/4
•Nut, Keps #10-24
Bolt, Pivot
• STANDARD HARDWARE - - PURCHASE LOCALLY
NOTE: Alt component dimensions given In U.S. Inches.
1 inch B 25,4 mm
