PORTABLE DUST COLLECTOR PARTS LIST MODEL N0.152.213361
AWARNING
When servicing, use only CRAFTSMAN replacement parts. Use of any other parts may create a HAZARD or cause
product damage.
AWARNING
Any attempt to repair or replace electrical parts on this Dust Collector may create a HAZARD unless repair is done by
a qualified service technician. Repair service is available at your nearest Sears Service Center.
Always order by PART NUMBER, not by key number.
Key No. PART No. Description Qty. Key No. PART No. Description Qty.
1 OR90652 MOTOR ASSEMBLY (COLOR: BLACK) 1 23 STD541031 HEX NUT 5/16-18 1
2 OR90653 GASKET 1 24 OR65974 FILTER BAG, 30 MICRON 1
3 STD523105 HEX HEAD SCREW 5/16-18 X 1/2" 12 25 OR90662 LOCKING BAND 1
4 OR90615 LOCK WASHER 5/16" 12 26 OR90662 LOCKING BAND 1
"5 OR90655 BLOWER COVER ASSEMBLY ‘1 27 OR90663 COLLECTION BAG, 30 MICRON 1
(COLOR: PANTONE 877)
INCLUDES: 1-OR90656 & 1-OR90607
*28 OR90664 BLOWER HOUSING ASSEMBLY
(COLOR: PANTONE 877) INCLUDES: *1
6 OR90657 GASKET 1 1-OR90670. 1-OR90600. 2-OR90601 &
7 OR90615 LOCK WASHER 5/16" 4
2-OR90598
8 STD523107 HEX HEAD SCREW 5/16-18 X 3/4" 4
29 OR92134 FLANGE HEX NUT 5/16-18 4
9 OR90658 IMPELLER 1
31 OR90615 LOCK WASHER 5/16" 4
10 STD551031 FLAT WASHER 5/16" 1
32 STD523106 HEX HEAD SCREW 5/16-18 X 5/8“ 4
11 STD.523107 HEX HEAD SCREW 5/16-18 X 3/4" 1
33 STD523106 HEX HEAD SCREW 5/16-18 X 5/8" 4
12 OR90628 SWITCH BOX ASSEMBLY (COLOR: BLACK) 1
35 OR92132 FLANGE HEX NUT 3/8-16 4
13 OR90727 CLAMP 1
37 OR90665 SIDE SUPPORT (COLOR: PANTONE 877) 2
14 OR90659 CAPACITOR 50uf 1
38 OR90648 SWIVEL CASTER 4
15 STD511003 PAN HEAD SCREW #10-24 X 3/8“ 3
39 OR90650 INTAKE PORT CAP 1
16 OR90630 TRUSS HEAD SCREW #10-24 X 3/8" 1
40 OR65935 4“ HOSE CLAMP 2
17 OR90631 SWITCH ASSEMBLY
41 OR90717 4“ X 6' FLEXIBLE HOSE 1
18 OR90632 SWITCH KEY (COLOR: YELLOW) 1
42 STD523106 HEX HEAD SCREW 5/16-18 X 5/8" 4
19 OR92133 MOTOR SPEC LABEL 1
43 OR90667 SUPPORT (COLOR: PANTONE 877) 1
20 OR90633 POWER CORD 1
44 OR92134 FLANGE HEX NUT 5/16-18 4
21 OR90660 UPPER HANGER (COLOR: PANTONE 877) 1
45 OR90668 BASE (COLOR: BLACK) 1
22 OR90661 LOWER HANGER (COLOR: PANTONE 877) 1
N/A OR92136 OWNER'S MANUAL FOR MODEL #213361
(NOT SHOWN) 1
18
