ACCESSORIES AND ATTACHMENTS CARTON CONTENTS
RECOMMENDED ACCESSORIES
Visit your Sears Hardware Department or see the
Craftsman Power and Hand Tools Catalog to purchase
recommended accessories for this power toot.
AWARNING
To avoid the risk of personal injury:
•
Do not use adjustable (wobble) type dadoes or
carbide tipped dado blades, maximum dado width
is 1/2".
• Do not use a dado with a diameter larger than 6".
• Do not use molding head set with this saw.
• Do not modify this power tool or use accessories not
recommended by Sears.
TOOLS NEEDED FOR ASSEMBLY
TOOLS NEEDED
Medium screwdriver
(I3DB=
#2 Phillips screwdriver
I..............
Straight edge Combination square
UNPACKING AND CHECKING CONTENTS
Separate all parts from packing material. Check each one
with the illustration and the list of loose parts to make
certain all items are accounted for, before discarding any
packing material.
AWARNING
To avoid personal injury, if any parts are missing, do not
attempt to assemble the table saw, plug in the power
cord, or turn the switch on until the missing parts are
obtained and are installed correctly.
TABLE OF LOOSE PARTS
ITEM DESCRIPTION QUANTITY
SAW
A. Table saw i
B. Blade guard and splitter 1
C. Bolt, flat washer, toothed washer, leach
oval washer
D. Rip fence handle 1
E. Rip fence 1
F. Hand wheels 2
G. Dome nuts 2
H. Dado table insert 1
I. Miter gauge 1
J. Hex keys 2
K. Blade wrenches 2
STAND
L. Top bracket (short) 2
M. Top bracket (long) 2
N. Bottom bracket (short) 2
O. Bottom bracket (long) 2
R Legs 4
Q. Bag of bolts, nuts, foot pads i
NOTE: To make assembly easier, keep contents of box
together. Apply a coat of automobile wax to the table.
Wipe all parts thoroughly with a clean dry cloth. This will
reduce friction when pushing the workpiece.
