Craftsman 137.218250 - Manual (Page 28)

Key Part No. Description Size Qty
158 14901302 Spring 1
159 2603BBLA66 Hex. socket set screw Ml0*1.5-12 1
160 2701FBD111 Hex. nut M10*1.5T=4 1
161 2701 FED 110 Hex. nut M10*1.5T=8 1
162 2615B8DD25 Hex head screw
& washer
M8*1.25-16 1
163 2672BBDA40 Cap head square
neck bolt
M6*1.0-16 2
164 2570BBN116 C-ring A-16 1
165 14935102 Supporting plate 1
166 14935001 Nut 1
167 2672BBDA44 Cap head square
neck bolt
M6*1.0-35 1
168 14922901 Spacer 1
169 2701FBD106 Hex nut M6*1.0 T=5 1
170 2501NBDN09 Flat washer 1/4*3/4-7/64 1
171 2502ABC417 Flat washer 66 1
172 2701FBD106 Hex nut M6*1.0T=5 1
173 2709FBDA02 Hex nut
& flat washer
M6*1.0 1
174 14920003 Motor bracket 1
175 14920301 Spacer 1
176 2701FBD105 Hex nut M 5*0.8 T=4 1
177 2615BBDC25 Hex head screw
and washer
M8*1.25-16 4
178 2672BBDB50 Cap head square
neck bolt
M8*1.25-16 4
179 2536MBE621 Spring pin 8-90 1
*
137218250001 Owner's Manual 1
>
H
in
tn
O
30
m
n
n
n
O
3D
>
■n
H
w
>
00
n
m
(0 I
o
a
m
Not Shown
