Key
Part No.
Description
S52S
Qfy
Key
Part No.
Description
Size
Qty
1
3BS00101
BASE
1
41
3AE09601
SAFETY SWTTCH
1
2
3BS00201
UPPER ARM
1
42
3AE04601
BALL BEARING
626ZZ
2
3
3BS00301
UPPER COVER, INNER
1
43
3BS04301
PLASTIC BRUSH ASSY.
1
4
3BS00401
COMPLETED MOTORW/CORD
1
44
3BS04401
STEEL WASHER
3/8”*19
2
5
3BS00501
FRAME ARM COVER, UPPER
1
45
3AE01301
KEY
5'5*54
1
6
3BS00601
BRAME ARM COVER, LOWER
1
46
3BS04601
FLAT KEY
5'5*32.5
1
7
3BS00701
POST SEAT
1
47
3BS04701
KNOB
1
8
3BS00801
SLiDING BKT.
1
48
3BS04801
FLAT WASHER
3/8”*23
1
9
3BS00901
UPPER WHEEL SHAFT HINGE
1
49
3BS04901
HEX. SCREW
3/8"*1-l/2
1
10
3BS01001
SHAFT OF UPPPER WHEEL
1
50
3BS05001
FLAT WASHER
3/8”*19
1
11
3BS01101
ADJUST KNOB ASSY.
1
51
3BS05101
HEX. SCREW
3/4"*20/2”
1
12
3BS01201
GUIDE P0ST(V TYPE)
1
52
3BS05201
FLAT WASHER
3/4"
2
13
3BS01301
GUIDE SUPPORT BRACKET BLADE GUARD
1
53
3BS05301
HEX, NUT
3/4;
1
14
ЗАЕ04501
BEARING SHAFT
2
54
3BS05401
NYLON NUT
1
15
ЗАЕ04701
Y TYPE BLOCK
2
55
3BS05501
TOOTH WASHER
5mm
2
16
3BS01601
ADJUST SPRING
1
56
3BS05601
COPPER WASHER
2
17
3BS01701
SQUARE NUT
1
57
3BS05701
SCREW [CROSS 1EADIW/I WASfER 3 /16" * 1 /4"
2
18
3BS01801
STAR KNOB
5/l6"*-2"
1
58
3BS05801
STEEL WASHER
3/16-14
4
19
3BS01901
BUTTERFLY NUT
5/18"
1
59
3BS05901
STEEL WASHER
5/l6*-23
2
20
3BS02001
PIN
2
60
3AE06201
LOWER SUPPORT BKT
1
21
3BS02101
SCREW(HEADLESS) 5/l6"*5/l6"
1
61
3BS06101
HEX. SCREW
l/4"*3/4"
2
22
3BS02201
SPRING
1
62
3BS06201
FLAT WASHER
1/4"*16
2
23
3BS02301
STEEL BALL
1/4"
1
63
3AE04801
STEEL PIN
4
24
3BS02401
STAR KNOB
5/l6:*1-1/4"
1
64
3AE06901
SET SCREW(HEADLESSl
M6*16
1
25
ЗАЕ08701
POWER CORD STORAE
2
65
3BS06501
SCrapCSS llEASlWTTIi W/1Sl€R3/l6''*3/8"
13
26
3BS02601
BLADE GUARD, LOWER
1
66
3AE01201
CROSS HEAD SCREW
3/l6"*3/8"
2
27
3BS02701
PLATE
2
67
3BS06701
HEADLESS CROSS SCREW
3/l6"*3/8"
2
28
ЗАЕ08401
POWER CORD W/PLUG
SJT18*3C‘2.3m 1
68
3BS0B801
SET SCREW
l/4*l/4
5
29
ЗАЕ08501
ГОШ cm W.teiPLUG SJT18*3C*2R
1
69
3AE04901
SET SCREW
l/4*l/2
4
30
ЗАЕ08601
STRAIN RELIEF BUSHING
6N-4
2
70
3BS07001
CROSS HEAD SCREW
3/l6"*l/4"
2
31
ЗАЕ01101
BEARING COVER
1
71
3BS07101
SPRING WASHER
3/4"
1
32
ЗАЕ00501
C RING
S-15
1
72
3BS07201
MOTOR LABEL
1
33
ЗАЕ00401
BALL BEARING
6202ZZ
2
73
3BS07301
LOWER GUIDE HOLDER ASSY.
1
34
3BS03401
PIN
2
74
3AE08801
CROSS HEADOTWWii WASHER 3/l6"*l/2"
2
35
3BS03501
FIXTURE BOLT
2
75
3BS07501
UPPER GUIDE HOLDER ASSY.
1
3 6
ЗАЕ06801
MOTOR PULLEY
1
76
3BS07601
SPRING WASHER
3/16"
2
37
3BS03701
SHAFT OF LOWER WHEEL
1
77
3BS07701
HEX. SCREW
5/l6"*1-l/4"
4
38
3BS03801
HEX. FIXTURE BOLT
2
78
3BS07801
FLAT WASHER
5/lS"*23"
8
39
3BS03901
CLIP HEAD'
2
79
3BS07901
HEX. NUT
5/16"
4
40
3BS04001
GUARD
ABS
1
>
