Craftsman 139.53664SRT2 - Manual (Page 32)

Operation of Your Opener
Activate the opener with any of the foliowing:
• The Remote Control: Hold push button down until
the door starts to move.
• The Door Control: Hold push button down until the
door starts to move.
• The Outdoor Key Switch or Keyless Entry:
(See Accessories)
When the opener is activated with the safety
reversing sensor installed and correctly aligned:
1. If open, the door will close, if closed, it will open.
2. If closing, the door will reverse.
3. If opening, the door will stop (allowing space for
entry and exit of pets and for fresh air).
4. If the door has been stopped in a partially open
position, it will close.
5. If obstructed while closing, the door will reverse.
6. If obstructed while opening, the door will stop.
7. The garage door will reverse in the closing cycle,
and the opener lights will blink for 5 seconds, when
the invisible beam is broken. If fully open, the door
will not close when the beam is broken. The sensor
has no effect in the opening cycle.
If the sensor is not installed, or is not aligned correctly,
the door won't close from any remote transmitter. You
can close the door with the Door Control, the Outdoor
Key Switch, or Keyless Entry, however, if you activate
them unti! down travel is complete. If you release them
too soon, the door will reverse.
The Opener Lights will turn on under the following
conditions: When the opener is initially plugged in;
when the power is interrupted; when the opener is
activated. It will turn off automatically after 4-1/2
minutes or provide constant light when the Light
feature on the Premium Control Console is activated.
Bulb size is 75 watts maximum.
SECURITY+ models: Lights will also turn on when
someone walks through the open garage door. With a
Premium Control Console, this feature may be turned
off as follows: With the opener lights off, press and
hold the light button for 10 seconds, until the light
goes on and off again. To restore this feature, start
with the opener lights on, then press and hold the light
button for 10 seconds.
Weak or broken springs could allow an open
door to fall (either rapidly or unexpectedly),
resulting in serious injury, death or property
damage. If possible, use the emergency
release rope and handle only when the door is
fully closed.
Release Arm
Trolley
Emergency
Release Handle
(Pull Down)
Manual disconnect
position
Trolley
Emergency
Release Handle
(Pull Down & Back
Towards Opener)
Lockout position
To open the door
manually;
The door should be fully
closed if possible. Pull
down on the red
emergency release
handle and lift the door
manually. To reconnect
the door to the opener,
press the Door Control
push button.
The lockout feature
prevents the trolley from
reconnecting automatically.
Pull the emergency handle
down and back (toward the
opener). The door can then
be raised and lowered
manually as often as
necessary. To disengage
the Lockout Feature, pull
the emergency handle
straight down. The trolley
will reconnect on the next
UP or Down operation.
Operation of the Door Controls
{SECURITY+ models: See additional programming features, next page.)
Press the lighted push button to open or close the
door.
Press again to reverseVne door during the closing
cycle or to stopXhe door while it's opening.
Premium Console:
Light Feature - Press the large round Light button. If
the opener lights are off, they will turn on. If the
opener lights are on, (even in the 4-1/2 minute
automatic cycle) they will turn off.
But if you use the Light button to turn the lights on
and then activate the opener, the lights will turn off
after 4-1/2 minutes.
The Light button will not control the opener lights
when the door is in motion.
Premium Console (cont.):
Lock Feature-Ihe Lock feature is designed to
prevent operation of the door from remote controls.
However, the door will
open and c/osefrom the Door
Control, the Outdoor Key Switch and the Keyless
Entry Accessories.
To Activate: Press and hold the small round Lock
button for 2 seconds. The push button light will flash
as long as the Lock feature is on.
To turn off: Press and hold the Lock button again for
2 seconds.The push button light will stop flashing.
The Lock feature will also turn off whenever the
“SRT’ button on the opener panel is activated.
32
