ASSEMBLY & ADJUSTMENTS cont.
INSTALLING THE SAFETY GUARD cont. (Figs. 4 and 4a )
4. Insert the edge of the guard into the slot along the back of the trimmer’s head, carefullly
lining the 4 screw holes in the guard up with the 4 screw holes in the trimmer head.
5. Insert screws and securely attach the safety guard (see Fig. 4a).
NOTE: Safety Guard will only fit one way.
/K CAUTION:
Line cutter on edge of safety guard is sharp. Use caution
when handling.
THE EDGE GUIDE (Fig. 5)
Your trimmer comes with an Edge Guide
that is handy for use as a cutting guide.
It can be used to help keep the cutting line
away from items you don’t want cut,
such as flowers, or damaged, such as
fences or screens.
Each end of the wire edge guide is force-fitted
into a hole located on each side of the trimmer’s
head. To use the edge guide, pull (force) it down
into the guide position as shown in Fig. 5.
