Connecting Cord
There are following three types of connecting jacks at the rear of the deck. Each type of jack requires a different type of
connecting cord.
Jack Required cord
LINE IN/OUT (analog input/output) jacks
Audio signal connecting cord
(supplied, or optional RK-C77 etc.)
Red White
LINE OUT White Red LINE IN
COAXIAL IN/OUT (digital input/output) jacks
Coaxial digital connecting cord
(optional VMC-1ES, etc.)
COAXIAL ^ ^ ' COAXIAL
OUT IN
Optical cable
OPTICAL OUT (optional POC-15, etc.) OPTICAL IN
OPTICAL IN/OUT (optical transmission digital
input/output) jacks
Connecting the Remote Control System
•й •и O O Bl
r-' 1
CONTROL'S
IN
^to an AC outlet
Amplifier or receiver
I ■ I
CONTROL'S
OUT
---------1—, r
to a wall outlet
13
