[D INPUT selector indicators
The OPTICAL or COAXIAL indicator lights according to
the position of the INPUT selector. No indicator lights when
the INPUT selector is set to the ANALOG position.
m SAMPLING FREQ. (Sampling frequency) indicator
48 kHz: For recording/piayback of analog input signals
(standard mode)
44.1 kHz: For recording/piayback of CD or a pre-recorded
DAT cassette
32 kHz: For recording/piayback of analog input signals
(long-play mode)
Qi REPEAT indicators
REPEAT 1: Lights when a desired selection is played
back repeatedly.
REPEAT ALL: Lights when all the selections are played
back repeatedly.
m] AMS (Automatic Music Sensor)/RMS (Random
Music Sensor) indicators
Show the number of selections to be skipped ahead or
behind in the AMS operation. When designating aselection
directly by the numeric button and the ► button, the
display shows the program number of the target selection
while the selection is being searched for. When
programming the desired selections in the RMS operation
(page 38), the display shows the program number of the
selection to be programmed.
m DISPLAY OFF/AUTO indicators
The DISPLAY OFF indicator lights when peak level meters
and margin indicators are turned off. The DISPLAY OFF
AUTO indicator lights momentarily before all the indicators
are turned off.
m SKIP PLAY indicator
When this indicator is lit during playback, the portion
marked by the skip ID is skipped and playback continues
from the next start ID.
| h | music scan indicator
Lights after pressing the MUSIC SCAN button to listen to
the beginning of each selection successively.
QD CAUTION indicator
Lights when moisture condensation occurs. If this happens,
the deck stops functioning automatically. (See page 4.)
im START 10 mode indicators
AUTO: Lights when the AUTO button is pressed to write
the start ID automatically.
RENUMBER; Lights when the RENUMBER button is
pressed to renumber the program numbers.
WRITE: Lights when writing the start ID manually.
ERASE: Lights when erasing the start ID.
AUTO RENUMBER: Lights when renumbering program
numbers automatically.
SHIFT RENUMBER: Lights when shifting the start ID and
program number position.
QZl SKIP ID mode indicator
WRITE: Lights when writing the skip ID.
ERASE: Lights when erasing the skip ID.
01)
END ID mode indicator
WRITE: Lights w/hen vwiting the end ID.
ERASE: Lights when erasing the end ID.
QD START ID indicator
Flashes when writing (for 9 or 18 seconds) or erasing a
start ID code, and lights when the start ID is detected durin
playback.
SKIP ID indicator
Lights when writing (for 1 or 2 seconds) or erasing a skip
ID code or when the skip ID is detected during playback.
mi MARGIN indicator
Shows how much margin there is between the peak level
of input audio signal and 0 dB.
m REHEARSAL indicator
Lights while the rehearsal function is activated (page 28).
m COPY PROHIBIT indicator
Lights when recording the digital signal with the copy
prohibit code. In this case, record with the LINE IN jacks.
M STEP/PGM NO. indicator
Shows the program number of the selection being played.
When programming the desired selection in the RMS
operation (page 38), the display shows the step number
of the programmed selection.
mi Frequencies map
When pressing the 4 button while keeping the COUNTER
MODE button pressed, bars indicating the sampling
frequencies with which the tape was recorded appear on
the peak level meters.
imi Peak level meters
Indicate the level of the audio signal being recorded
during recording, and the peak values of the audio signal
recorded on the tape during playback.
mi Tape operation indicators
I r E c I: Lights during recording or in the record-pause
mode.
►: Lights during recording or playback. It also lights in the
record-pause mode or in the play-pause mode.
II; Lights in the record-pause mode or in the play-pause
mode.
