Additional Information
Self-diagnosis Function
This monitor is equipped with a self-diagnosis function. Use
this function if there is a problem with your monitor or
computer.
1
Disconnect the video input cable or turn ofTthe
connected computer.
2
Turn the monitor off and on.
3
Press and hold the button for 2 seconds.
If all four color bars app>ear (white, red, green, blue) after
a few seconds, the monitor is working properly but there
might be a problem with your computer. Contact your
computer's manufacturer.
If the color bars do not appear, there is a potential
morutor failure. Inform your authorized Sony dealer of
the monitor's condition.
Specifications
CPD-220GS
Picture tube
Viewable image size
Resolution
Standard image area
Deflection frequency
Plug & Play
Speaker
Headphones output
Audio input
0.25 mm aperture grille pitch
17 inches measured diagonally
90-degree deflection
Approx. 327 X 243 mm (w/h)
(12^/8x9^/8inches)
16.0" viewing image
Horizontal: Max. 1280 dots
Vertical: Max. 1024 lines
Approx. 312
X
234 mm (w/h)
(12 ^/8
X
9
' / 4
inches)
Horizontal: 30 to 85 kHz
Vertical: 48 to 120 Hz
DDCl/2B/2Bi,GTF
0.25 W (monaural)
Stereo minijack. Accepts
impedance of 8il or more
Stereo minijack
AC input voltage/current
100-120-1.9 A 50/60 Hz
Power consumption
Dimensions
Mass
Supplied accessories
220-240-1.1 A 50-60 Hz
Max. 120 W
406 x 432 x 420 mm (w/h/d)
(16 X17 Vs x 16 ®/8 inches)
Approx. 18 kg (39 lb 11 oz)
See page 6
Design and specifications are subject to change without
notice.
20
