Introduction


Legend™ 1200E Wash User Manual Rev. 02e

-3-

2. Introduction

Product

Description

The Legend™ 1200E Wash is a moving yoke fixture with a 1200 W short arc discharge
lamp. It contains an LCD control panel (display), through which all of the settings can
be set or modified.

This fixture can operate at 200~240 VAC, 50/60 Hz, which eliminates the need for a
voltage selection switch. The ballast and igniter in the lamp circuit are both of the
electronic type.

Features

• 16 or 21-channel DMX moving yoke
• Pan: 540⁰ in 2.8 sec
• Tilt: 270⁰ in 1.6 sec
• Color wheel 1:

Seven colors + white (red, blue, pink, green, yellow, orange, and UV)

Split/linear colors

Rainbow color spin at variable speeds both wheels

• Color wheel 2:

Seven colors + white (5,600 K, magenta, light blue, light green, light yellow,
pink, and dark blue

Split/linear colors

Rainbow color spin at variable speeds both wheels

• Variable CTC filter (3,200~6,000 K)
• CMY color mixing system with vector speed adjustments
• Variable shutter
• Variable 16-bit dimming (0~100%)
• Linear zoom (5.6~20.75⁰)
• Individual reset of pan/tilt, color, shutter, and zoom
• Remote fixture reset, lamp on/off, vector speed adjustments
• Built-in movement macros with range adjustments
• Built-in color macros

Additional Features

• 3-pin and 5-pin DMX connections
• User-configurable lamp ignition delay
• User-configurable maintenance reminder
• Electronic ballast with power factor correction
• Electronic power supply
• Automatic pan & tilt correction
• Pan & tilt locks
• Lamp and fixture use timer
• Power saver mode

Options

• W-DMX (wireless DMX) receiver
• W-DMX (wireless DMX) transmitter
