Operation
-18- Legend™ 1200E Wash User Manual Rev. 02e
Offset Mode The Offset Mode provides fine adjustments for the home position of all the moving parts
in the optical path as well as the pan and tilt movements. The home position is where
the moving parts go when you reset them. In their corresponding home position, the
moving parts should not show any border or reduce the light output. It they do, use the
Offset Mode to fine adjust them.
Entering Offset
Mode
1) Press
2) Press for more than three seconds to enter the Offset Mode (the Offset
Mode menu will show).
4) Press
Pan Motor
1) Select Pan and press (a pop up window will open).
a) Select the new value (-128~127).
b) Accept the new value.
Tilt Motor
1) Select Tilt and press (a pop up window will open).
a) Select the new value (-128~127).
b) Accept the new value.
Shutter Motor
1) Select Shutter and press (a pop up window will open).
a) Select the new value (0~255).
b) Accept the new value.
Color 1 Motor
1) Select Color 1 and press (a pop up window will open).
a) Select the new value (-128~127).
b) Accept the new value.
Color 2 Motor
1) Select Color 2 and press (a pop up window will open).
a) Select the new value (-128~127).
b) Accept the new value.
Cyan Dichroic Flag
1) Select Cyan and press (a pop up window will open).
a) Select the new value (0~255).
b) Accept the new value.
Magenta Dichroic Flag
Motor
1) Select Magenta and press (a pop up window will open).
a) Select the new value (0~255).
b) Accept the new value.
Yellow Dichroic Flag
1) Select Yellow Filter and press (a pop up window will open).
a) Select the new value (0~255).
b) Accept the new value.
3200 K Filter Dichroic Flag
1) Select 3200 K Filter and press (a pop up window will open).
a) Select the new value (0~255).
b) Accept the new value.
Zoom Motor
1) Select Zoom and press .
a) Select the new value (0~255).
b) Accept the new value.
