Operation
-20- Legend™ 1200E Wash User Manual Rev. 02e
Mode 2 (Advanced)
Ch # Function Value Percent/Setting
1 Pan 000  255 0~540º
2 Pan Fine 000  255 0~100%
3 Tilt 000  255 0~270º
4 Tilt Fine 000  255 0~100%
5 Pan/Tilt Speed 000  255 Fast~Slow
6 Dimmer 000  255 0~100%
7 Dimmer Fine 000  255 0~100%
8 Shutter
000  015
016  131
132  167
168  203
204  239
240  247
248  255
Open
Slow ~Fast
Slow open/Fast close
Fast open/Slow close
Slow open/Slow close
Random strobe
Open
9 Color 1
000  007
008  015
016  023
024  031
032  039
040  047
048  055
056  063
064  127
128  189
190  191
192  255
Open (white)
Dark Blue
Pink
Light Yellow
Light Green
Light Blue
Magenta
5600 K
Split Colors
CCW rotation (fast~slow)
Stop
CW rotation (slow~fast)
10 Color 2
000  007
008  015
016  023
024  031
032  039
040  047
048  055
056  063
064  127
128  189
190  193
194  255
Open (white)
Red
Blue
Pink
Green
Yellow
Orange
UV Purple
Split Colors
CCW rotation (fast~slow)
Stop
CW rotation (slow~fast)
11 Cyan 000  255 0~100%
12 Magenta 000  255 0~100%
13 Yellow 000  255 0~100%
14
3200 K / CTO
Filter
000  255 0~100%
15 Filters Speed 000  255 0~100%
16 Zoom
000  007
008  255
No Function
0~100%
17 Preset Color
000  021
022  042
043  063
064  085
086  106
107  127
128  148
149  170
171  191
192  212
213  233
234  255
Open (white)
Color 1
Color 2
Color 3
Color 4
Color 5
Color 6
Color 7
Color 8
Color 9
Color 10
Color 11
Ch # Function Value Percent/Setting
18 Color Macro
000  007
008  049
050  091
092  133
134  175
176  217
218  255
Open
Macro 1
Macro 2
Macro 3
Macro 4
Macro 5
Macro 6
19 Pan/Tilt Macro
000  007
008  015
016  023
024  031
032  039
040  047
048  055
056  063
064  071
072  079
080  087
088  095
096  103
104  120
121  127
128  135
136  143
144  151
152  159
160  167
168  175
176  183
184  191
192  207
208  223
224  231
232  247
248  255
Off
Macro 1
Macro 2
Macro 3
Macro 4
Macro 5
Macro 6
Macro 7
Macro 8
Macro 9
Macro 10
Macro 11
Macro 12
Macro 13
Macro 14
Macro 15
Macro 16
Macro 17
Macro 18
Macro 19
Macro 20
Macro 21
Macro 22
Macro 23
Macro 24
Macro 25
Macro 26
Macro 27
20
Pan/Tilt Macro
Range
000  255 0~100%
21 Function
000  069
070  079
080  089
090  099
100  109
110  129
130  139
140  149
150  159
160  169
170  179
180  189
190  199
200  209
210  229
230  239
240  255
No function
Pan/tilt blackout (enable)
Pan/tilt blackout (disable)
Color blackout (enable)
Color blackout (disable)
No function
Lamp On
Pan/tilt reset
Color reset
No function
Shutter reset
Zoom reset
No function
Reset all
No function
Lamp off
No function
