Operation
Legend™ 1200E Wash User Manual Rev. 02e -19-
DMX Values
Mode 1 (Basic)
Ch # Function Value Percent/Setting
1 Pan 000  255 0~540º
2 Pan Fine 000  255 0~100%
3 Tilt 000  255 0~270º
4 Tilt Fine 000  255 0~100%
5 Pan/Tilt Speed 000  255 Fast~Slow
6 Dimmer 000  255 0~100%
7 Shutter
000  015
016  131
132  167
168  203
204  239
240  247
248  255
Open
Slow ~Fast
Slow open/Fast close
Fast open/Slow close
Slow open/Slow close
Random strobe
Open
8 Color 1
000  007
008  015
016  023
024  031
032  039
040  047
048  055
056  063
064  127
128  189
190  191
192  255
Open (white)
Dark Blue
Pink
Light Yellow
Light Green
Light Blue
Magenta
5600 K
Split Colors
CCW rotation (fast~slow)
Stop
CW rotation (slow~fast)
9 Color 2
000  007
008  015
016  023
024  031
032  039
040  047
048  055
056  063
064  127
128  189
190  193
194  255
Open (white)
Red
Blue
Pink
Green
Yellow
Orange
UV Purple
Split Colors
CCW rotation (fast~slow)
Stop
CW rotation (slow~fast)
Ch # Function Value Percent/Setting
10 Cyan 000  255 0~100%
11 Magenta 000  255 0~100%
12 Yellow 000  255 0~100%
13 3200 K Filter 000  255 0~100%
14 Preset Color
000  021
022  042
043  063
064  085
086  106
107  127
128  148
149  170
171  191
192  212
213  233
234  255
Open (white)
Color 1
Color 2
Color 3
Color 4
Color 5
Color 6
Color 7
Color 8
Color 9
Color 10
Color 11
15 Zoom
000  007
008  255
No Function
0%
 100%
16 Function
000  069
070  079
080  089
090  099
100  109
110  129
130  139
140  149
150  159
160  169
170  179
180  189
190  199
200  209
210  229
230  239
240  255
No function
Pan/tilt blackout (enable)
Pan/tilt blackout (disable)
Color blackout (enable)
Color blackout (disable)
No function
Lamp On
Pan/tilt reset
Color reset
No function
Shutter reset
Zoom reset
No function
Reset all
No function
Lamp off
No function
