Operation Manual - JUICE BOX™ Settings
For Race Use Only
The Juice Box™ is legal ONLY for closed course race vehicles. The Juice Box™ is not
applicable, nor inteded for use on EMISSIONS CONTROLLED street, highway or off-road
vehicles. The Juice Box™ is not applicable, nor inteded for use on aircraft.
Mode 1 - green
Mode 4 - green/blue Mode 5 - Yellow/blue Mode 6 - red/blue
Mode 2 - Yellow Mode 3 - red
Pre-set Settings: Raptor 700 with stock airbox, TBR Slip-on exhaust with spark arrestor. (G=3 Y=3.5, R=2, GB=N/A, YB=3, RB=3)
(Same settings for Raptor 700 with airbox lid off, TBR Slip-on exhaust with NO spark arrestor and P1 Power Tip installed.)
Additional Tested Setting: Raptor 700 with airbox lid off and TBR Slip-on exhaust with spark arrestor.
(G=3, Y=4, R=2.5, GB=N/A, YB=3, RB=3)
For additional settings please visit our website at www.twobros.com.
Mode 1 - green
Mode 4 - green/blue Mode 5 - Yellow/blue Mode 6 - red/blue
Mode 2 - Yellow Mode 3 - red
Two Brothers Racing
Juice Box™ - Fuel Controller
2006-08 Yamaha Raptor 700 Installation & Operation Manual
Part # 008-138
