ITBR001-327 www.twobros.com 2013 Kawasaki EX300 - 4
10. Attach the connectors from the Juice Box Pro wiring harness to the TPS and stock
wiring harness as shown in Figure E.
Note: Make sure you do not plug the Juice Box Pro to the stock black connector.
Figure D
9. Locate and unplug the Throttle Position Sensor (TPS) on the right-hand side of the
throttle bodies as shown in Figure D.
The TPS is a grey 3-pin connector.
Figure D was taken with the coolant bottle moved out of the way.
Figure E
Figure F
11. Using the supplied velcro, secure the Juice Box Pro module in the tail section as
shown in Figure F.
Make sure to clean both surfaces with the alcohol swab before attaching.
12. Reinstall the fuel tank and seats.
unplug
Juice Box Pro
stock
Juice Box Pro
TPS
