ITBR001-287 www.twobros.com 2010 Honda VFR1200 - 3
Figure A
Figure B
Figure C
6. Attach the ground wire from the Juice Box Pro to the negative side of the battery
as shown in Figure B.
7. Remove the rear fuel tank bolt and route the Juice Box Pro harness to the inside
of the frame mount as shown in Figure C.
8. Reinstall the tank bolt.
harness
ground
harness
1. Remove the seat and side fairings.
2. Remove the cosmetic covers around the fuel tank.
3. Prop the front of the fuel tank up.
4. Secure the Juice Box Pro in the trunk area using the supplied Velcro as shown in
Figure A.
Make sure to clean both surfaces with the alcohol swab before attaching.
5. Route the Juice Box Pro harness towards the airbox going along the left side of
the bike.
