Fuses
Usage
PCM 1
Powertrain Control Module
ETC/ECM
Electronic Throttle Control,
Electronic Brake Controller
IGN E
Instrument Panel Cluster, Air
Conditioning Relay, Turn
Signal/Hazard Switch, Starter
Relay, Electronic Brake
Controller TC2 Mode Switch
RTD
Electronic Suspension
Control, Automatic Level
Control (ALC) Exhaust
TRL B/U
Backup Lamps Trailer Wiring
F/PMP
Fuel Pump (Relay)
B/U LP
Back-up Lamps, Automatic
Transmission Shift Lock
Control System
RR DEFOG
Rear Window Defogger
HDLP-HI
Headlamp High Beam Relay
PRIME
Not Used
AIRBAG
Supplemental Inflatable
Restraint System
FRT PARK
Front Parking Lamps,
Sidemarker Lamps
DRL
Daytime Running
Lamps (Relay)
SEO IGN
Rear Defog Relay
Fuses
Usage
TBC IGN1
Truck Body Controller Ignition
HI HDLP-LT
Driver’s Side High Beam
Headlamp
LH HID
Not Used
DRL
Daytime Running Lamps
RVC
Regulated Voltage Control
IPC/DIC
Instrument Panel
Cluster/Driver Information
Center
HVAC/ECAS
Climate Control Controller
CIG LTR
Cigarette Lighter
HI HDLP-RT
Passenger’s Side High Beam
Headlamp
HDLP-LOW
Headlamp Low Beam Relay
A/C COMP
Air Conditioning Compressor
Relay
A/C COMP
Air Conditioning Compressor
TCMB
Transmission Control Module
RR WPR
Rear Wiper/Washer
RADIO
Audio System
SEO B1
Mid-Bussed Electrical Center,
Universal Home Remote
System, Rear Heated Seats
LO HDLP-LT
Driver’s Side Headlamp
Low Beam
5-114
