*1 — Gasoline Engine and Fuel Injection Rail #2.

*2 — Gasoline Engine and Fuel Injection Rail #1.

*3 — Gasoline Engine; Oxygen Sensors.

*4 — Gasoline Engine; Oxygen Sensors.

*5 — Ignition 1

*6 — Powertrain Control Module, Fuel Pump.

*7 — Rear Climate Control.

*8 — Sunroof.

Fuses

Usage

GLOW PLUG

Not Used

CUST FEED

Gasoline Accessory Power

HYBRID

Not Used

STUD #1

Accessory Power/Trailer
Wiring

MBEC 1

Mid Bussed Electrical Center
Power Feed, Front Seats,
Right Doors

BLWR

Front Climate Control Fan

LBEC 2

Left Bussed Electrical
Center, Door Modules,
Door Locks, Auxiliary Power
Outlet — Rear Cargo Area
and Instrument Panel

Fuses

Usage

STUD #2*

Accessory Power/Trailer
Wiring Brake Feed

ABS

Anti-lock Brakes

VSES/ECAS

Automatic Level Control
(ALC) Compressor

IGN A

Ignition Switch

IGN B

Ignition Switch

LBEC 1

Left Bussed Electrical Center,
Left Doors, Truck Body
Controller, Flasher Module

TRL PARK

Parking Lamps Trailer Wiring

RR PARK

Right Rear Parking and
Sidemarker Lamps

LR PARK

Left Rear Parking and
Sidemarker Lamps

PARK LP

Parking Lamps Relay

STRTR

Starter Relay

INTPARK

Roof Marker Lamps

STOP LP

Stoplamps

TBC BATT

Truck Body Controller Battery
Feed

SEO B2

Off-Road Lamps

4WS

Not Used

AUX PWR

Auxiliary Power
Outlet — Console

5-113
