Fuses

Usage

HTR A/C

Climate Control System

LCK

Power Door Lock Relay
(Lock Function)

HVAC 1

Inside Rearview Mirror,
Climate Control System

LT DR

Driver’s Door Harness
Connection

CRUISE

Cruise Control

UNLCK

Power Door Lock Relay
(Unlock Function)

RR FOG LP

Not Used

BRAKE

Brake Switch

DRIVER UNLCK

Power Door Lock Relay
(Driver’s Door Unlock
Function)

IGN 0

Brake Transmission Shift
Interlock, Powertrain Control
Module, Transmission

TBC IGN 0

Truck Body Controller

VEH CHMSL

Vehicle and Trailer High
Mounted Stoplamp

LT TRLR ST/TRN

Left Turn Signal/Stop Trailer

LT TRN

Left Turn Signals and
Sidemarkers

Fuses

Usage

VEH STOP

Vehicle Stoplamps, Brake
Module, Electronic Throttle
Control Module

RT TRLR ST/TRN

Right Turn Signal/Stop Trailer

RT TRN

Right Turn Signals and
Sidemarkers

BODY

Harness Connector

DDM

Driver Door Module

AUX PWR 2, M/GATE

Instrument Panel Outlets,
Rear Cargo Area Power
Outlets

LCKS

Rear Doors and Liftgate
Power Lock Relay Feed

ECC TPM

Liftgate, Tire Pressure
Monitoring System

TBC 2C

Truck Body Controller

HAZRD

Flasher Module

CB LT DRS

Left Rear Power Window
Circuit Breaker and Driver
Door Module

TBC 2B

Truck Body Controller

TBC 2A

Truck Body Controller
