PARTS LIST
11
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from
those on your particular grill model. However, the method of assembly remains the same.
Not Pictured:
Key Qty Description
…
2
DOOR MAGNET
…
1
WRENCH, F/ CASTERS
…
1
HARDWARE PACK
…
1
ASSEMBLY MANUAL, ENGLISH
…
1
ASSEMBLY MANUAL, SPANISH
Key
Qty Description
A
1
OUTER TOP LID
B
1
INNER LINER, F/ LID
C
1
HANDLE, F/ TOP LID
D
2
END CAPS, F/ HANDLE
E
1
LOGO PLATE, W/ TEMP GAUGE
F
1
HARDWARE F/ TOP LID
G
2
RUBBER BUMPER, RECTANGLE
H
2
RUBBER BUMPER, ROUND
I
1
FIREBOX
J
1
HEAT SHIELD, F/ FIREBOX, FRONT
K
1
LEFT SIDE OUTER PANEL, F/ FIREBOX
L
1
RIGHT SIDE OUTER PANEL, F/ FIREBOX
M
1
MATCH HOLDER AND CHAIN
N
1
REAR PANEL, UPPER FIREBOX
O
3
MAIN BURNER
P
1
ELECTRODE, F/ LEFT MAIN BURNER
Q
2
ELECTRODE, F/ MIDDLE & RIGHT MAIN
BURNER
R
1
HOSE/VALVE/REGULATOR
S
1
MAIN CONTROL PANEL
T
1
IGNITOR SWITCH MODULE
U
4
BEZEL, F/ KNOB
V
4
CONTROL KNOB
W
1
LEFT SIDE PANEL, F/ CART
X
1
RIGHT SIDE PANEL, F/ CART
Y
1
CAP F/ ELECTRONIC MODULE
Z
1
ELECTRONIC MODULE
AA
1
HEAT SHIELD, F/ ELECTRONIC MODULE
BB
1
LOWER BACK PANEL, F/ CART
CC
1
HEAT SHIELD, F/ TANK
DD
1
FRONT BRACE W/ DOOR MAGNET
EE
1
UPPER BACK PANEL, F/ CART
FF
1
LEFT DOOR, NO HANDLE
GG
2
HANDLE, F/ DOOR
HH
1
RIGHT DOOR, NO HANDLE
II
1
BOTTOM SHELF
JJ
1
TROUGH, SINGLE
KK
1
SIDEBURNER DRIP PAN
LL
1
LEFT SIDE SHELF F/ S/B
MM
1
CONTROL PANEL, F/ LEFT SIDE SHELF
NN
1
LID, F/ SB
OO
2
RUBBER BUMPER, F/ SB
Key
Qty Description
PP
1
RIGHT SIDE SHELF
1
FASCIA, RIGHT SIDE SHELF
RR
3
COOKING GRATE, MAIN
SS
1
WARMING RACK
TT
1
SIDEBURNER
UU
1
ELECTRODE, F/ SIDEBURNER
VV
1
SIDEBURNER GRATE
WW
1
HEAT SHIELD, LOWER, FIREBOX, 500, '09
XX 2
CASTER, LOCKING
YY 2
CASTER, FIXED
ZZ
1
IGNITOR WIRE, F/ SIDEBURNER
AAA
1
GROMMET
BBB
1
TANK SCREW
