VZ309 34
8. Wire Connections
Note:
• Before installing, be sure to disconnect the negative cable of the car battery.
• In the optional devices, the RCA cables and the Connector cables are separately-sold
items.
Radio
Antenna
Jack
Connector cable
(Sold separately)
Subwoofer
Line Out
Video Out 1
Reverse
Parking
To Amplifier
Purple/
White
Green
Video Out
Video In
Fuse 15
To Power
Antenna or Amp.
ACC/ Ignition
Purple
Yellow
Yellow
Yellow
Camera In
Yellow
Rear Line Out
Gray
Front Line Out
Black
Purple (+)
Purple/Black (-)
Green (+)
Green/Black (-)
R (Red)
L (White)
R (Red)
L (White)
R Speaker
Rear
L Speaker
Rear
Gray (+)
Gray/Black (-) R Speaker
Front
White (+)
Blue/White
Red
Black
Yellow
White/Black (-)
L Speaker
Front
To Factory
Ground
+1V
Main Power Filter
Box
HD Radio
Satellite Radio
iPod
Module
XM Radio
Tuner
