English
VZ309 30
INSTALLATION /WIRE
CONNECTION GUIDE
CONTENTS
1.BEFORE STARTING .............................................................. 30
.PACKAGE CONTENTS .......................................................... 30
3. GENERAL CAUTIONS .......................................................... 30
4. CAUTIONS ON INSTALLATION ............................................ 31
5. INSTALLING THE SOURCE UNIT ........................................ 31
. REMOVING THE SOURCE UNIT .......................................... 3
7. CAUTIONS ON WIRING ........................................................ 33
8. WIRE CONNECTIOS............................................................. 34
1. Before Starting
1. This set is exclusively for use in cars with a
negative ground 1 V power supply.
. Read these instructions carefully.
3. Be sure to disconnect the battery“ ”terminal
before starting. This is to prevent short circuits
during installation. (Figure 1)
Source unit ..................................................... 1
Owner’s manual and Installation manual ........ 1
Mounting bracket ............................................ 1
Machine screws M5x mm ............................. 4
Mounting bolt (50 mm) .................................... 1
Parking wire .................................................... 1
Removable face plate case ............................ 1 Trim plate ................................... 1
T-key ..........................................
Rubber cushion ......................... 1
Remote control unit ................... 1
Battery (CR05) ...................... 1
(Installed in remote control)
2. Package Contents
3. General Cautions
1. Do not open the case. There are no
user- serviceable parts inside. If you
drop anything into the unit during
installation, consult your dealer or an
authorized Clarion service center. . Use a soft, dry cloth to clean the case.
Never use a rough cloth, thinner,
benzine, or alcohol etc. For tough dirt,
apply a little cold or warm water to a soft
cloth and wipe off the dirt gently.
