Genel yapılandırmalar, San ortamına bağlanan ana sunucularınızı kablolama – Dell POWERVAULT MD3620I User Manual
Page 185
Sisteminizi Kullanmaya Ba
ş
larken
183
Genel Yapılandırmalar
SAN Ortamına Ba
ğ
lanan Ana Sunucularınızı Kablolama
Sunucular, anahtarlar ve depolama dizileri arasındaki tüm kabloları a
şağıdaki
şekilde gösterildiği gibi bağlayın. Depolama dizilerini kablolamaya ilişkin
daha fazla örnek için, support.dell.com/manuals adresindeki Uygulama
Kılavuzu'na bakın.
En fazla 64 ana makine
Sunucu 1
Sunucu 2
Depolama dizisi
Kurumsal, kamu
veya özel a
ğ
Anahtar 1
Anahtar 2
