Autoloader Power Specifications
Autoloader Vibration Specifications
Autoloader Shock Specifications
Tape Drive Specifications
LTO5-140 SAS Drive Specifications
Media Capacity
Media Specifications
Back to Contents Page
Characteristic Specification
Line voltage 60 Hz system: 90 – 265 VAC
50 Hz system: 90 – 265 VAC
Line frequency 47 – 63 Hz
AC Input current 60 Hz system: 4.0 A (RMS) for 115 VAC
50 Hz system: 2.0 A (RMS) for 230 VAC
Power consumption 60 Hz = 75 W (256 BTU/hr)
50 Hz = 80 W (273 BTU/hr)
Characteristic Specification
Operating
Random Vibration 0.26 Grms, 5 – 350 Hz (X, Y, Z) axes
Nonoperating
Random Vibration 1.54 Grms, 10 – 250 Hz (X, Y, Z) axes
Characteristic Specification
Operating 31 G, 2.6 ms half-sine, 2 pulses (+/–) per axis, X, Y, Z
Nonoperating 71 G, 2 ms half-sine, 2 shocks (+/–) per axis, X, Y, Z
Description LTO5-140 SAS
Read/write transfer rate: maximum sustained
(LTO Ultrium 5 media) Non-compressed mode: 500 GB/hr
Compressed (2:1 typical): 1000 GB/hr
Burst transfer rate 140 MB/s
Average access time 52 seconds (from BOT)
Loading time to BOT
(for previously written tape) 19 seconds (maximum)
Unloading time from BOT 19 seconds (maximum)
MCBF > 100,000 cartridge load/unload cycles
Interface type Serial Attached SCSI (SAS)
Media type Capacity
LTO Ultrium 5 storage capacity 4800 GB (compressed) with 16 cartridges
Characteristic LTO Ultrium 5
LTO Ultrium 5 formatted capacity 1500 GB (non-compressed)
3000 GB (2:1 typical compression)
Basic description Dual coat metal particle
Tape length 846 m (2775.6 ft)
Cartridge dimensions 10.2 x 10.54 x 2.15 cm
(4 x 4.15 x .85 in)
Read compatibility LTO Ultrium 3, LTO Ultrium 4, and LTO Ultrium 5
Write compatibility LTO Ultrium 4 and LTO Ultrium 5
Shelf life > 30 years with < 10% loss in demagnetization @ 20°C
40% RH (non-condensing)
Cartridge life 1,000,000 passes (any point on the tape passing the recording head in either direction)
LTO Universal Cleaning cartridge life 50 uses
