56 Internal Card With Bluetooth ® Wireless Technology
Replacing the Bluetooth Card
1 Follow the instructions in "Before You Begin" on page 9.
2 Slide the Bluetooth card into the slot on the computer base and secure it
in place.
3 Connect the Bluetooth-card cable to the system-board connector.
4 Replace the palm-rest assembly (see "Replacing the Palm-Rest Assembly"
on page 40).
5 Replace the optical drive (see "Replacing the Optical Drive" on page 34).
6 Follow the instructions in step 5 in "Replacing the Hard Drive(s)" on
page 30.
7 Replace the memory module(s) (see "Replacing the Memory Module(s)"
on page 18).
8 Replace the module cover (see "Replacing the Module Cover" on page 16).
1 Bluetooth-card cable 2 Bluetooth card
1
2
