16 Module Cover
Replacing the Module Cover
1 Follow the instructions in "Before You Begin" on page 9.
2 Align the tabs on the module cover with the slots on the base cover and
snap the module cover into place.
3 Tighten the captive screw that secures the module cover to the base cover.
4 Replace the battery (see "Replacing the Battery" on page 14).
1 base cover 2 tabs
3 module cover 4 captive screw
1
2
3
4
