General Specifications A-4
• DIGITAL OUT: Front, Rear, Center and Subwoofer SPDIF digital outputs
❑ Three line-level analog outputs via 3.5 mm minijacks on rear bracket: front, rear, and rear center/
center/subwoofer Line-Outs 1, 2 and 3
❑ Stereo headphone (32-ohm load) support on Front Line-Out
SB1394/FireWire Inter-
faces ❑ One 2 x 5 pin Internal SB1394/FireWire connector on card
❑ One 6-pin SB1394/FireWire port on rear bracket
Interfaces ❑ AD_EXT 2 x 20 pin header for connection to Audigy 2 Drive
❑ JOYSTICK 2 x 8 pin header* for connection to the Joystick/MIDI connector (optional attachment)
The 6-pin SB1394/FireWire
connector/port has a 3 watt
maximum power output.
Connect only one high power
usage device such as the IEEE
1394 hard disk and CD-RW
drive to this port unless it is self-
powered.
