Installing Hardware 1-3
Table 1: Description of Jacks, Connectors and Ports.
Number Description
1 SB1394/FireWire port (SB1394/FireWire)
Connects to an IEEE 1394 compatible external device (such as a digital video
camcorder, digital still camera, printer or scanner).
2 Line Out 3 jack (LIN_OUT3)
Connects to Front Center, Subwoofer and Rear Center Out of powered analog
speakers or an external amplifier for audio output.
3 Line Out 2 jack (LIN_OUT2)
Connects to Rear Left/Right Out of powered analog speakers or an external
amplifier for audio output.
4 Line Out 1 jack (LIN_OUT1)
Connects to Front Left/Right Out of powered analog speakers or an external
amplifier for audio output. Also supports headphones.
5 Microphone In jack (MIC_IN)
Connects to an external microphone for voice input.
6 Line In jack (LIN_IN)
Connects to an external device
(such as a cassette, DAT or MiniDisc player).
7 Digital Out jack
6-channel or compressed AC-3 SPDIF output for connection to external digital
devices or digital speaker systems.
Click here or on any description in
the table to return to the main
diagram.
